“Y” Shaped Sacral Fragility Fracture Treatment with the Curvafix IM System - Case Study

Oct. 18, 2022- By: Joshua L. Gary

CASE PRESENTATION
A 68-year-old female with some dysmorphism and mild osteoporosis had a fall in the shower, resulting in a Y-shaped sacral fracture and non-displaced fractures of the superior and inferior pubic ramus.

Most popular related searches

CASE PLANNING
Fixation in S1 was required because S2 was distal to the transverse component of the sacral fracture.

FIXATION
A standard 7.3-mm screw was inserted at the left hemipelvis.Then. a CurvaFix IM implant (140 mm in length) stabilized the Y-shaped sacral fracture across S1-2.

FOLLOW-UP
At 2 weeks, the patient was ambulatory with paracetamol for pain.
At 6 weeks, the patient was walking well with no pain.
At 3 months, the patient`s fractures were healed and the patient was asymptomatic.

KEY POINTS

Safe placement of transiliac-transsacral fixation in S1 of a dysmorphic pelvis would not have been possible with a straight screw.
A CurvaFix implant in S1 provided fixation without need for lumbopelvic stabilization with spinal implants.
