DIOLAS Photon - Compact Medical Diode Laser

The instrument which adapts to your needs

• Store your own user name and own set of treatment parameters
• Easily choose treatment parameters on-screen from the list of indications of your own medical discipline
• Configure the laser system with accessories such as handpiece holders, etc. according to your preferences

Main Features

• World`s first compact laser with LFD (Levelled Field Density) Mode which limits coagulation to a constant 1 mm for clearly reduced collateral damage
• Large 10,4 " True Color Touch Panel for easy and intuitive use
• Compact, lightweight and easy to carry
• Multi-user system for infinite storage of individual user programs
• Interactive assistant program for easy selection of treatment parameters

• Dermatology & Aesthetics
• ENT (Ear Nose Throat)
• Dentistry
• General Surgery
• Proctology
• Urology
• Thoracic Surgery & Pneumology

• DIOLAS Photon Pro
  High-power advanced model
  • 30 Watt @ 980 nm, alternatively 810 nm
  • 50 Watt @ 980 nm, alternatively 810 nm
  • 30 Watt @ LFD Mode
  • 50 Watt @ LFD Mode
• DIOLAS Photon Duo
  Powerful dual-mode model
  • 30 Watt @ CW 980 nm + 25 Watt @ LFD Mode
  • 30 Watt @ CW 810 nm + 25 Watt @ LFD Mode

• Fibers & Handpieces
• Fiber Repair Kit
• Eye Protection
• Smoke Evacuator VACULAS 4000
