Exxelia Ohmcraft - Model HVD Series -High Voltage Radial Leaded Dividers
The HVD Series by Ohmcraft offers high voltage radial leaded resistor dividers utilizing the company's patented Micropen precision printing technology. This technology ensures high precision in thick-film radial through hole resistors. The HVD Series features absolute tolerance of 15% unless otherwise specified, with TCR tracking typically below 25°C ppm/°C. These resistors are constructed with a 96% Alumina substrate and are encapsulated in glass with optional single side epoxy or powder coating for enhanced durability. The series supports custom sizes and configurations to meet specific requirements, highlighting its adaptability for various applications such as medical, test & measurement, power supplies, defense, and aerospace. For customized specifications, users are encouraged to consult with Ohmcraft’s sales team to tailor the components to precise needs.Most popular related searches
Our patented Micropen® precision printing technology provides superior precision, thick-film radial through hole resistor dividers.
- Voltage Ratings to 40,000 Volts
- Resistance Values to 2 TΩ
- Ratio Tolerances to 0.1%
- Ultra High Stability
- Very Low Noise
- VCR to 0.05 ppm/V
- TCR to 25 ppm/°C
- TCR Tracking to 5 ppm/°C
- Custom Configurations
Wire Leads:
22AWG (0.025″),
1.3″ typical lengthSpade Leads:
0.01” thick, 0.02” wide, 0.325”
minimum length, standoff 0.06” max.
