- 8-in-1 Functionality: Active pressure measurement, HP shut-off valve, Filling port with check valve, RPV, Pressure regulator, PRD, Flow selector and Medical outlet connection
- Integrated design is safer, easy to use, and more compact
- Available in many different configurations
- Medical CE certified according to MDD 93/42/EEC. Complies with EN ISO 10524-3 and CGA E-18
- Available with Rotarex Meditec intelligent electronic system
- Gas Type Oxygen, Air, N2O/O2 Mixture
- Upper Limit Working Pressure 100 bar 1450 PSI
- Inlet Pressure 200, 300 bar 2900 PSI
- Outlet Pressure 3,5, 4,5 bar 43.5 PSI
- Flow settings 0-2, 0-6, 0-15 liters/minute
- Inlet connection 25E, 17E, 3/4" - 16 UNF
- Outlet connection Hose barb (ISO 13544-2)
- Filling connection CGA 540, CGA 577, ISO W24x2, ISO W30x2, W22x14R
- Body material Chrome-plated brass
- Seat material PA 6.6
- O-ring material EPDM
- Filter material Sintered bronze 20 μm
- Lower Operating Temperature Limit -20 Celsius -4 Fahrenheit
- Upper Operating Temperature Limit 60 Celsius 140 Fahrenheit
