GTI - Model G-A2-1-AWD320 -Manual Door Spray Washer for Medical Equipment Disinfection
The G-A2-1-AWD320 is a cost-effective manual door spray washer designed by Galbino to meet the needs of smaller hospitals and institutions. It matches the performance and washing efficacy of the G-A2-1-AWD520 model. Key applications include disinfection of surgical instruments, wares, medical trays, anesthesia tools, and corrugated hoses in hospital central sterile supply departments (CSSD) or operating rooms. It features a double pull-down door design, offering a convenient working platform for load handling. The interlocked doors provide self-lock functionality. Enhanced visibility and safety during operations are ensured through a triple-layered tempered glass window. The washer uses an LCD screen for process monitoring, and a Siemens PLC for intelligent operation and control. Users can select from 11 preset programs and create 15 customized ones. It accommodates 12 DIN trays per cycle with operating parameters like a disinfection temperature of 80-93°C and adjustable cycle times, offering reliable and efficient performance.G-A2-1-AWD320 is an economic Manual Door Spray Washer that researched and developed by Galbino according to requirements of smaller hospitals or institution. Its function and washing effective are equal with G-A2-1-AWD520.
Manual Door Spray Washer also can be used for disinfection of surgical instruments, wares, medical trays and plates, anesthesia instruments and corrugated hoses in hospital CSSD or operating room.
Manual Door Spray Washer Features:
◆ Manual Door Spray Washer door structure
Manual Door Spray Washer (G-A2-1-AWD320) adopts double pull-down door structure. After opening the door, it can be regarded as a working platform for loading the washing rack and items.
The double doors are interlocked and have self-lock function.
◆ Manual Door Spray Washer strong glass window
Three layers tempered glass window with excellent sealing ensures the security, insulation and easily observing during washing process.
◆ Manual Door Spray Washer operation system
LCD display screen can show all the temperature, pressure, time, process stage and parameters. Easily operation by touch button on the panel.
SIEMENS PLC ensures the machine intelligent running and control. Built-in printer can automatically record the temperature, pressure, time, graph and A0 value
◆ Manual Door Spray Washer: A variety of programs
11 preset programs and 15 user-defined programs which can be edited according to user demands.
◆ Outstanding loading capacity
12 DIN trays per cycle in four layers.
