MRS*PET - Model CLIP-ON -PET Scanner for Both PET/CT and PET/MR Imaging
The cCLIP-ON is a versatile imaging system designed for both PET/CT and PET/MR applications, offering sequential imaging capabilities that facilitate efficient workflows. This portable system can be swiftly transferred between CT and MR setups, minimizing operational downtime and minimizing the need for multiple investments. The CLIP-ON technology involves a unique plug-and-play approach, making it compatible with CT and high-field MR up to 9.4T, thereby enhancing modularity and reducing costs for research institutes. It incorporates advanced silicon photomultiplier (SiPM) technology, allowing precise depth of interaction (DOI) with dual-layer pixelated scintillator crystals, achieving exceptional resolution under 0.8mm. Furthermore, MR SOLUTIONS integrates the MRS*DRYMAG technology, a cryogen-free MR technology operating up to 9.4T without liquid helium or nitrogen. The system is enhanced by the Preclinical Scan multimodality imaging software, which offers a comprehensive user interface for manipulating MRI, PET, SPECT, and CT functionalities effectively.
The MRS*PET CLIP-ON is designed for sequential PET/MR and PET/CT imaging. The system can be moved between the CT and the MR within minutes. This dramatically improves the workflow and limits the investment as only one PET CLIP-ON is required for multiple imaging configuration. The PET CLIP-ON can also be operated as a Benchtop PET device.
- Sequential PET/MR imaging and PET/CT imaging
- Stand alone Benchtop PET
- Abality to image animals up to 12 kg with MRS*PET 220
- Compatible with MR up to 9.4T.
- PET field of view: Axial ≤ 150mm , transaxial ≤120 mm, Inner diameter ≤160 mm
- Animal type : ≤ 12 kg animals
- PET System type : CLIP-ON for PET/MR and PET/CT
- Detector type : Silicon Photomultipliers (SiPM)
- Crystal type : Double Layers, LYSO/LYSO, 10 mm
- Continuous detector : Yes
- PET removable from MR : Yes
- PET removable from CT : Yes
- PET CLIP-ON: Inner Diameter / Transaxial FOV : ≤150 mm (ID) & ≤120 mm (tFOV)
- Axial FOV (mm) : ≤ 150.40 mm
- Extended axial FOV (mm) : 300 mm with motorised bed
- Spatial Resolution with 3D OSEM (mm) : 0.7 mm
- Depth of Interaction (DOI) : Yes – true DOI
- Sensitivity : Up to 11% depending on configuration
