INJEX Pharma - Positive Pressure Respirator

1. Connect one end of the breathing tube to the air outlet of the breathing tube Host and the other end to the mask air inlet.
2. Attach the hip bag to the hip belt and tie it at the waist.
3. Start the respirator, wear a mask, set the gear and place it in the Bum bag.

The product sucks outside air through a fan into the respirator, flows through a pre-filter, a UVA LED and a main filter in turn remove toxic gases and particles in the air and finally is clean air sent out through the air outlet.

The pre-filter LED lights up and indicates that a new filter is required
Place the pre-filter. The user can buy a new one
Pre-filter to replace. Unscrew the base counterclockwise.
Take out the pre-filter and replace it with a new one. After the replacement is complete, press the reset button, the LED indicator will go out, and the usage time counter will reset again.
Then release the reset button and continue normal operation.

The main filter LED lights up, indicating that the main filter needs to be replaced. The user can –
Chase a new main filter to replace it. Unscrew the top cover, take out the main filter and reinsert it with a new one. After the exchange is complete,
Press the reset button, the replacement main filter, the LED light goes out and the timer for use goes out again to be reset, then release the reset button and continue normal operation.

The product is suitable for medical personnel to wear during surgery and to provide users with fresh and clean air and to prevent the influence of pathogenic microorganisms, liquids, and particles.

Pre-filter

Eliminate large particles and protect the main filter

1. waterproof
2. Little pressure drop
3. Interchangeable

Mainfilter

ULPA-Filter

1. Low pressure drop, high dust collection efficiency
2. Excellent moisture resistance
3. Excellent water resistance
4. Interchangeable

Battery

Power indicator 1 LED (Yellow)) Battery low, red light ;
Fan speed display 3 LED (Green)) Fan speed display ;
Pre-filter light 1 LED (Red)) Indicates that the pre-filter needs to be replaced ;
Main filter light 1 LED (Red)) Indicates that the main filter needs to be replaced ;

Mainbutton

2-in-1 button that is used as the power button and fan speed button (Press for 5 seconds to turn on, 5 seconds to turn on turn off)
Operating temperature -10 ~ ~ 50 ?, humidity 5% ~ 95%
