ADP9000 Smart DP Transmitter

Smart Differential Pressure TransmitterModel ADP9000 SeriesGENERAL ADP9000 series is a digital differential pressure transmitter designed for industrial pressure measurement applications.The ADP9000 offer Configurations for Differential, gas, absolute pressureand vacuum liquid-Level measurements including integrated solutions forpressure, level and flow.FEATURESUpdating time of output current in 200 msImproved performance, increased accuracy, greater stabilityTwo Years stability of 0.2%0.075% accuracyParameter setting by the use of local keypad 4-20 mA output plus direct digital HART communicationAutomatic zero calibration by press buttonExplosion proof and weather proof housingSPECIFICATIONProcess Fluid : Liquid, Gas of Vapor Display : 5 Digits programmable & 0-100% BargraphApplication : Differential Pressure, Gauge Pressure, Display Unit : Standard 22 engineering unitAbsolute Pressure 5 Digits programmable for special unitMeasuring Range : 0 - 0.125 Kpa ~ 0 - 1.5 Kpa ( Minimum ) Keyboard : 3 keys from internal for Programming: 0 - 4.0 Mpa ~ 0 - 25.0 Mpa ( Maximum ) and output settingTurn Down Ratio : 1 : 100 Current Output : 4 - 20 mA 2 wires with Hart SignalAccuracy : +/- 0.075% of span Load : Rohm=(Vdc-9)*50Stability : +/-0.15% of URL for 2 years Power Supply : 9 - 36 VDCWorking Temperature : -25 to +95 °C Damping Adjustment : 0 - 32 SecondMax. Pressure : 40 Mpa Response Time : 200 mSMaterial Mounting : Bracket on 2" PipeFlange/Adapters : Stainless Steel 304 / Stainless Steel 316 Humidity Limits : 0 to 100% Relative HumidityDrains/Vents : Stainless Steel 304 / Stainless Steel 316 Turn on Time : 2 Seconds with minimum dampingDiaphragms : Stainless Steel 316L / Hastelloy B / Zero calibration : Automatic zero calibration by press buttonHastelloy C / Monel / Tantalum Electrical Connections : M20 Conduit Threads / 1/2" NPT( Female )Wetted O-Rings : Buna N / Viton / PTFE Temperature Effect : +/-0.18% of span per 20 °CBolts & Nuts : Carbon Steel / Stainless Steel 316 Vibration Effect : +/-0.05% of URL per g to 200 Hz in anyMounting Bracket : Carbon steel / Stainless Steel 304 / 316 axisName / Tag Plate : Stainless Steel 304 / Stainless Steel 316 EMI/RFI Effect : Follow SAMA PMC 33.1 from 20 to 1000Converter Housing : Low copper cast aluminum alloy with MHz and for field strengths up to 30 V/mpolyurethane, light blue paint Process connections : 1/4 - 18 NPTFill Fluid : Silicone / Fluorine Oil : 1/2 - 14 NPT( with Adapter )Enclosure : IP67 ( Standard ) Ambient Temperature : -25 to +80 °C: Intrinsically Safe EEx ia IIC T5 ( Standard ) Dimensions : 102 mm ( W ) * 188 mm ( H ) * 130 mm (D): Explosion proof Ex D IIB T5 Weight : 3.5 KgALIA GROUP INC. URL : www.alia-inc.com113 Barksdale Professional Center, Newark, DE 19711, USA E-mail : alia@alia-inc.comTEL : + 1 - 302 - 213 - 0106 FAX : + 1 - 302 - 213 - 0107 ADP9000V1.1.8enALIADP ALIADP®ALIADP Smart Differential Pressure Transmitter ADP9000 SeriesDifferential Gauge Absolute Pressure Pressure Pressure0 - 0.125 Kpa 0 - 1.5 Kpa 0 - 12.75 mmH2O 0 - 153.0 mmH2O0 - 1.250 mbar 0 - 15 mbar 0 - 0.5018 InH2O 0 - 6.022 InH2O0 - 0.018 psi 0 - 0.218 psi 0 - 0.001 Kg/cm2 0 - 0.015 Kg/cm20 - 1.3 Kpa 0 - 7.5 Kpa 0 - 132.6 mmH2O 0 - 764.8 mmH2O0 - 13 mbar 0 - 75 mbar 0 - 5.219 InH2O 0 - 30.11 InH2O0 - 0.189 psi 0 - 1.088 psi 0 - 0.013 Kg/cm2 0 - 0.076 Kg/cm20 - 6.2 Kpa 0 - 37 Kpa 0 - 632.2 mmH2O 0 - 3773 mmH2O0 - 62 mbar 0 - 370 mbar 0 - 24.89 InH2O 0 - 148.5 InH2O0 - 0.899 psi 0 - 5.366 psi 0 - 0.063 Kg/cm2 0 - 0.377 Kg/cm20 - 30 Kpa 0 - 180 Kpa 0 - 3.059 MH2O 0 - 18.35 MH2O0 - 300 mbar 0 - 1800 mbar 0 - 120.4 InH2O 0 - 722.6 InH2O0 - 4.351 psi 0 - 26.11 psi 0 - 0.306 Kg/cm2 0 - 1.835 Kg/cm20 - 117 Kpa 0 - 690 Kpa 0 - 11.93 MH2O 0 - 70.36 MH2O0 - 1.170 Bar 0 - 6.900 Bar 0 - 469.7 InH2O 0 - 2770 InH2O0 - 16.97 psi 0 - 100.1 psi 0 - 1.193 Kg/cm2 0 - 7.036 Kg/cm20 - 350 Kpa 0 - 2000 Kpa 0 - 35.69 MH2O 0 - 203.9 MH2O0 - 3.5 Bar 0 - 20 Bar 0 - 1405 InH2O 0 - 8029 InH2O0 - 50.76 psi 0 - 290.1 psi 0 - 3.569 Kg/cm2 0 - 20.39 Kg/cm20 - 1.17 Mpa 0 - 6.8 Mpa 0 - 119.3 MH2O 0 - 693.4 MH2O0 - 11.70 Bar 0 - 68 Bar 0 - 4697.1 InH2O 0 - 27299 InH2O0 - 169.7 psi 0 - 986.3 psi 0 - 11.93 Kg/cm2 0 - 69.34 Kg/cm20 - 4.0 Mpa 0 - 25 Mpa 0 - 407.9 MH2O 0 - 2549 MH2O0 - 40 Bar 0 - 250 Bar 0 - 16059 InH2O 0 - 100366 InH2O0 - 580.2 psi 0 - 3626 psi 0 - 40.79 Kg/cm2 0 - 254.9 Kg/cm2ALIA GROUP INC. ADP9000V1.1.8en? ??? ?? ? ?? ?Page 2Low Range Low RangeHigh Range High Range? ? ???4Transmitter? ?? ??Pressure RangeMEASURE RANGERangeCode23??ELECTRICAL CONNECTION56789Z S-++ -9~36VDCmA-+ALIADP Smart Differential Pressure Transmitter ADP9000 SeriesALIA GROUP INC. ADP9000V1.1.8enDIMENSIONSSupply & Load RequirementsPage 39 15 21 27 33 3602505007501000Load ( )O Power Supply (VDC)1250DG8.892mm130mm102mm 130mmS ZKPA0.000L54mm85mm60mm188mmDG8.8DG8.8DG8.8HALIADP Smart Differential Pressure Transmitter ADP9000 SeriesModel Selection GuideADP9000- X X -X X X -X X X -X X X -XX DescriptionD Differential pressure transmitterG Gauge pressure transmitterA Absolute pressure transmitter2 0 - 0.125 (0.015) Kpa ... 0 - 1.5 Kpa (Type D/G)3 0 - 1.3 (0.075) Kpa ... 0 - 7.5 Kpa (Type D/G)4 0 - 6.2 (0.37) Kpa ... 0 - 37 Kpa5 0 - 30 (1.8) Kpa ... 0 - 180 Kpa6 0 - 117 (6.9) Kpa ... 0 - 690 Kpa7 0 - 350 (20) Kpa ... 0 - 2000 Kpa8 0 - 1.17 (0.068) Mpa ... 0 - 6.8 Mpa9 0 - 4.0 (0.25) Mpa ... 0 - 25 Mpa-N Stainless Steel 316L-B Hastelloy B-C Hastelloy C-P Monel-T TantalumN Stainless Steel 304S Stainless Steel 316N Carbon SteelS Stainless Steel 316-N Carbon Steel-4 Stainless Steel 304-6 Stainless Steel 316N Burn-NV VitonP PTFEN SiliconeF Fluorine-N 1/4" - 18 NPT-A 1/2" - 14 NPT( with Adapter)-Z OtherN M20 Conduit ThreadsP 1/2" NPT( Female)Z OtherN 4 MPa1 6.4 MPa2 16 MPa3 40 MPa-NN None-EX Explosion proof Ex D IIB T5-S6 Stainless Steel 316 Name Plate and Tag Plate-HT Hart Signal-ZZ OthersALIA GROUP INC. ADP9000V1.1.8en Page 4Wetted O-ring MaterialFill FluidPressure RangeMounting Bracket MaterialMaximum Pressure LimitsElectrical ConnectionsProcess ConnectionsBolts / Nuts MaterialProcess Flanges, Drain/Ventvalve MaterialOptionADP9000 SeriesExample:ADP9000-D3-CNS-6NF-NNN-EX/S6TypeDiaphragm Material
