Drew Scientific - Model D3 - 3-Part CBC Analyzer

• Cell Counters for Clinical Hematology
• Cell Counters for Veterinary Hematology and Research
• Reagents and Controls

Drew Scientific has been making leading edge and top quality CBC systems for over 15 years. The Drew-3 is the latest innovative offering.

• 16 parameters
• 60 samples per hour
• 10 µL sample size (whole blood) + pre-diluted mode
• Large LCD color touchscreen for ease of use
• Data management stores up to 1000 sample records and QC statistics
• User-friendly operator interface with multilanguage capability
• Low reagent consumption

• WBC,  Lymp#,  Gran#,  Mids#
• Lymp%,  Gran%,  Mids%
• RBC, Hgb, Hct, MCV, MCH, MCHC, RDW, Plt, MPV
• The system also displays :
• WBC, Plt and RBC histogram

• All operations are controlled via the large touch screen.
• This includes start-up and shut-down, run samples, datalog, QC, Reagents.
• Four different operator levels are possible including Lab Manager and Lab Tech.
• Operators are logged at start-up or when a new operator takes over.

• Blood samples must be collected in EDTA tubes. Sample sizes :
• Direct mode : 10 µL whole blood
• Pre-diluted / Capillary : 25 µL into 0.5ml of diluent using a built in diluent dispenser

• 60 samples per hour in direct sampling mode

• A compact 3 reagent pack is provided. Packs are coded with lot number and expiry date to give full traceability.

• Six controls levels, 3 months each. Assay values can be entered via the keypad or loaded from a USB key. Automatic calculation of mean, SD and CV% (possible to reject bad samples). Levey Jennings plot per level. It is possible to upload results to USB key for peer to peer analysis.

• The Drew-3 is controlled via a large colour touchscreen.
• The software is designed to make the instrument as easy to use as possible.
• Up to 1000 sample results can be stored on the system and results can be backed up on a USB key (flash disk).
