CO Check Pro - Model CO 30 - Baby Breath Tester

Ease of use is key in a busy smoking cessation clinic – from a single breath the results are instantly displayed in parts per million (PPM) and % carboxyhaemoglobin (%COHb), clear visual guidance is also provided with coloured red, yellow and green indicators dependent on the concentration  of exhaled carbon monoxide, indicating if the person is a non-smoker, light smoker, or heavy smoker.

The CO Check Pro Baby will also provide the level of foetal carboxyhaemoglobin. There is a clear correlation between the exhaled carbon monoxide on the pregnant mothers breath and that of the % carboxyhaemoglobin in the foetal blood supply (%FCOHb).

Additionally the CO Check Pro Baby is also capable of detecting environmental CO levels. When the Environmental Capture is enabled, background CO levels are taken into account when carrying out a breath test. If the background levels are 10ppm for example, then when the person is taking a breath test this background reading of 10ppm will be taken into account. Environmental levels are displayed in PPM.

It is widely accepted and acknowledged a non-smoker will perform a test and will display a level of 6ppm or less. A light smoker will perform a test and have a reading between 7 – 10ppm. A smoker will perform a test and have a reading of between 11 – 20ppm and a heavy smoker will display a reading of 21ppm or more.

• Results instantly displayed
• Measurement of foetal carboxyhaemoglobin levels
• Single press button to toggle between mothers expired level (ppm) and foetal carboxyhaemoglobin (%FCOHb) level
• Breath hold countdown timer to guide patients
• Coloured light indicators to signify smoking level
• %FCOHb light indicators – Green or Red dependent on levels recorded
• Measurement of environmental CO levels
• Supplied with Safebreath® mouthpieces to ensure a complete hygiene concept

• Gas Detected – Carbon Monoxide
• Concentration Range – 0-99 PPM
• Detection Sensor Used – Electrochemical fuel cell
• Sensitivity – 0.1 PPM (0-10 PPM range); 1 PPM (10-99PPM range)
• Accuracy (repeatability) – 2ppm or +/-5% whichever is greater
• Operating Temperature – 5° – 35° Celsius
• Operating Pressure – Atmospheric 10%
• Operating Humidity – 30% to 90% RH
• Operating Altitude – Sea level to 6000 ft
• Storage Temperature – minus 20° to + 70° C
• Storage Humidity – 10% to 90% RH
• Hydrogen cross-sensitivity – <12% at 20° C
• Sensor Life – 5 year warranty
• Sensor Drift – <2% per month
• Display – 128 X 64-pixel Graphic LCD
• Power Supply – Single 9V PP3 battery
• Weight (approximate) – 160g including battery
• Dimensions – 135mm x 65mm x 30mm
• *Indicator levels – Green 0 – 6 PPM, Yellow 7 – 10 PPM, Red 11 – 20 PPM, Flashing red 20+ PPM
• Results displayed – CO PPM (Carbon monoxide parts per million)
• %COHb (% carboxyhaemoglobin)
• %FCOHb  (% foetal carboxyhaemoglobin)
• CO Check Baby- Catalogue Number CO30
