CO Check Plus - Model CO 10 - Breath Carbon Monoxide Monitor

Users are guided to hold their breath with a count down timer and then encouraged to exhale with an on-screen blow icon to assist testing compliance.

The CO Check + comes complete with all accessories, CO level and %COHb guide chart and is supplied in a soft shell carry case for easy transport.

Additionally, the CO Check + is capable of detecting environmental CO levels. When the Environmental Capture is enabled, background CO levels are taken into account when carrying out a breath test, allowing any possible environmental exposure to be clearly identified. Environmental levels are displayed in PPM.

• Results instantly displayed on large display
• Single press button to toggle between ppm and %COHb
• Breath hold countdown timer to guide patients
• Measurement of environmental CO levels
• Supplied with Safebreath® mouthpieces to ensure a complete hygiene concept

• Gas Detected – Carbon Monoxide
• Concentration Range – 0-99 PPM
• Detection Sensor Used – Electrochemical fuel cell
• Sensitivity – 0.1 PPM (0-10 PPM range); 1 PPM (10-99PPM range)
• Accuracy (repeatability) – 2ppm or +/- 5% whichever is greater
• Operating Temperature – 5-35o Celsius
• Operation pressure – Atmospheric 10%
• Operating Humidity – 30% to 90% RH
• Operating Altitude – Sea level to 6000 ft
• Storage Temperature – minus 20 to + 70O C
• DOWNLOAD CO CHECK + BROCHURE
• Storage Humidity – 10% to 90% RH
• Hydrogen cross-sensitivity – <12% at 20° C
• Sensor Life – 5 year warranty
• Sensor Drift – <2% per month
• Display – Custom LCD
• Power Supply – Single 9V PP3 battery
• Weight Approximately – 150g including battery
• Dimensions – 135mm x 65mm x 30mm
• Results displayed – CO PPM (Carbon monoxide parts per million)
• %COHb (% carboxyhaemoglobin)
• %FCOHb  (% foetal carboxyhaemoglobin)
• CO Check + – Catalogue Number CO10
