Tailin - Model HTY-CPS -Cell and Gene Therapy Isolator

Customized Solutions for ATMP Products R&D and Production

Integrated VHPS® decontamination system
Special liquid transfer technology for continuous and aseptic filling
Real-time monitoring of the velocity, differential pressure, humidity, temperature
Temperature is adjustable to minimize the influence on products
Critical process parameters can be stored and printed
Power Supply: AC 380V/50Hz
Siemens PLC control with HMI
Leakage rate is less than 0.5% /vol/hour at 2 times working pressure
LED lamp, more than 300 Lux

Rapid Transfer Ports (RTP) technology for safe transfer

Particle counter

Air sampler

H2O2 high & low concentration sensors

H2O2 portable sensor for operator safety

WiFi controlled glove integrity tester (GIT-WLAN)

Wooden Mock-Up

Cell and Gene Therapy Isolator systems can be custom designed to suit individual customer requirements.

Complete validation protocols to comply with FDA, EMA, GMP, 21CFR Part 11.

FAT, SAT, Training.
