MD-Diagnostics - Model CO 50 - Co Screen Breath Tester

RAPID ASSESSMENT OF CARBON MONOXIDE POISONING FOR EMERGENCY SERVICES AND FIRST EMERGENCY RESPONDERS.

When dealing with CO, time is critical. In the blood stream Carbon Monoxide has an affinity with haemoglobin some 200 times greater than Oxygen. When this happens, the blood is no longer able to carry oxygen, and this lack of oxygen causes the body’s cells and tissue to die.

CO Screen will give instant breath results in %COHb and PPM. Both measurements are backed up with colour traffic lights for immediate visual display.

The new CO Screen, a rapid assessment of Carbon Monoxide poisoning for Emergency Services and First Emergency Responders.

• Results instantly displayed
• Results displayed in %COHb or ppm for easy interpretation
• No warm up time required
• Can be used on multiple patients with minimal effort (mouthpiece must be disposed of between patients)
• Configurable breath hold time dependent on operator preferences ranging from  0 to 20 seconds
• Configurable light indicator dependent on operator preference
• Hard shelled carrycase with mouthpieces for easy storage and transportation.
• Simple push button calibration

• Gas Detected – Carbon Monoxide
• Concentration Range – 0-42.5 %COHb (375 PPM)
• Detection Sensor Used – Electrochemical fuel cell
• Sensitivity – 1 % COHb
• Accuracy (repeatability) – ±3%
• Operating Temperature  – 5-35 degrees Celsius
• Operating Pressure – Atmospheric 10%
• Operating Humidity – 30% to 90% RH
• Operating Altitude – Sea level to 6000 ft
• Storage Temperature – minus 20 to + 70° C
• Storage Humidity – 10% to 90% RH
• Hydrogen cross-sensitivity – <15% at 20° C
• Sensor Life – 5 year warranty
• Sensor Drift – <2% per month
• Display – 128 X 64 pixel Graphic LCD
• Power Supply  – Single 9V PP3 battery
• Weight (approximate)   – 160g including battery
• Dimensions – 135mm x 65mm x 60mm
• Indicator levels – Green 0 – 9.9 %COHb, Yellow 10 – 19.9 %COHb, Red 20 – 29.9 %COHb, Flashing red 30+ %COHb
