Dolphin - Continuous Positive Airway Pressure (CPAP) System
Continuous positive airway pressure (CPAP) therapy supports the airways of preterm and low-birth weight newborns, who can breathe spontaneously but inadequately. It is a comfortable alternative to relatively invasive therapies, endotracheal intubation and mechanical ventilation. Dolphin CPAP system is designed to protect compromised airways, enhancing patient comfort and optimizing infant outcomes. Its continuous gentle pressure of air decreases the baby’s work of breathing by keeping the alveoli of the lungs open, enables efficient capillary exchange of oxygen and carbon dioxide to take place, helps establish and maintain functional residual capacity, prevents collapse and upper airway obstruction, and reduces apnoea, bradycardia and cyanotic episodes.
Easy To Use
The Dolphin bubble CPAP features electronic mixing for easy, independent adjustment of flow rate and FiO2.
Safe
The Dolphin combines a compact, quiet, and easy-to-operate technology with precise control of gas flow delivery and oxygen concentration. For added patient safety, the Dolphin incorporates a full complement of alarms.
Cost Efficient
The Dolphin combines proven clinical effectiveness in respiratory care and patient monitoring technology with exceptional value.
Quality
Dolphin CPAP sets a new standard for neonatal respiratory care, providing a noninvasive, clinically effective and safe therapy to treat newborns and infants with respiratory distress syndrome and other common respiratory pathologies. It accurately mixes air with oxygen, adds humidity to the gas mixture, and then delivers it to the patient at precisely-controlled flow rate.
Innovation
Designed with comfort in mind, Dolphin CPAP technology is a complete all-in-one CPAP treatment and monitoring device. Its integrated design includes gas mixing, humidification, PEEP chamber, air compressor and pulse-oximeter in one compact unit.
Care
Dolphin CPAP delivers high-quality pressure support to even the smallest and most fragile infants. It is suitable even for low birth weight infants and can be administered immediately after birth, ensuring that neonatal energy is reserved for growth and development.
Overall
100% reusable and cleanable
Complete all-in-one CPAP treatment and monitoring device
Integrated design includes gas mixing, humidification, PEEP chamber, air compressor and pulse-oximiter in one compact unit
PEEP/CPAP
Innovative design for safe and easy one hand adjustment
Easily visible at front of unit
Gas Mixing
Electronic mixing for easy, independent adjustment of flow rate and FiO2
Directly set FiO2, no calculations or tables
Internal regulator allows safe connection to a variety of oxygen sources
Humidifier
Automatically refills for 3-days continuous operation
Small heated volume for quick warm up
Heater power is automatically adjusted to maintain correct humidity and minimize rain-out
Patient Circuit
Completely reusable
Most parts autoclavable
Can be chemically disinfected if autoclave is not available
Includes internal heater wire and temperature sensors
Robust but flexible silicone tubes
Pulse Oximeter
Pulse-oximetry integrated into the device
Masimo SET® technology for accurate, reliable, robust measurements
Simple user interface and alarm settings
No multi-level menus or complicated button sequences
Air Compressor
Integrated air compressor means there is no need for an external air source
Completely integrated, no messy external wires or tubes
