Star - Model 3195 - Electric Operation Table
Electric Operation Table C-Arm Compatible Design, with dual Controls. ASCO Electric operation table is ergonomically designed to support the patient during various surgical procedures and interventions like general surgery, vascular surgery, endoscopy, neurosurgery, gynecology, urology and orthopedic procedures. ASCO OT table is as per international standards. Comes with switched-mode power supply (SMPS) based control Box. Comes with two control panels-one attached to table and other Wired remote control. Supplied with standard accessories and mattress.
Most popular related searches
surgery table
C-arm
leg section
vascular surgery
leg support
surgery endoscopy
surgery procedure
orthopedic procedure
patient positioning
general surgery
- C-Arm Compatible.
- Eccentric pillar for easy C-Arm access
- Radio-Translucent Top with five sections.
- In built kidney bridge.
- Detachable- head, leg & Pelvic section.
- Easily movable on castors.
- Table can lock easily with mechanical brakes.
- Made of stainless & acid-proof steel.
- Stepless articulation of the table Top for precise patient positioning.
- User friendly operations.
- Adaptive and versatile design make it suitable for various surgeries.
- Provides high patient safety and comfort.
- Easy to clean and sterilize.
- Optimal performance.
- Battery Back-up.
Table Positions
- Height Adjustment – Up & Down
- Lateral Tilt – Left & Right
- Trendelenburg & Reverse Trendelenburg
- Flex Position & Reflex Position
Standard Accessories
- StarA1- Shoulder Support (1 Pair)
- StarA2- Lateral Support (1 Pair)
- StarA3- Leg Support (1 Pair)
- StarA4- Arm Rest (1 Pair)
- StarA5- Anesthetic Screen (1 Piece)
- StarA7- Mattress (1 Set)
- Length of Table: 1900 mm
- Width of Table Top: 520 mm
- Minimum Height (without Mattress): Min. 750 mm
- Maximum Height (without Mattress): Max. 1000 mm
- Trendelenburg: 25°
- Reverse Trendelenburg: 25°
- Lateral Tilt: ±20°
- Back Section: ±70°
- Head Section: ±60°
- Leg Section: 0°-90°
- Top Sliding: 125mm Reerse & 125mm Forward
