Diamond Smartlyte - Model Plus - Electrolyte Analyzer
The Diamond Diagnostics SmartLyte® Plus Electrolyte Analyzer is a completely automated system measuring Na+, K+, Cl-, Ca++ and Li+ in whole blood, serum, plasma and urine utilizing Ion Selective Electrode (ISE) technology. The Diamond SmartLyte® Plus is uniquely designed with a powerful microprocessor allowing for easy interface with external LIS systems, operation with a new touch screen interface, bar code scanner and storage and retrieval of over 10,000 patient results. The system currently operates in over 12 languages and offers laboratories the option to utilize the analyzer for either human or veterinary applications.
Most popular related searches
- Power : 100-240V~ 50/60 Hz {self adjusting) 11.6 A max, 50 Watts max
- Size & Weight : 13.2x12.4x12in or 335x315x295 mm 14 lbs or 6 kgs
- Ambient Conditions : Room temperature: 15-32°C/60-90°F Humidity <85%
- User Input
- 5" Touch Screen
- Remote Access
- Analysis Time
- 28 sec (512/hour)
- Calibration
- 2 Point every 4 hours 1 Point every sample On Demand
- Data Storage
- 10.000 Patient Results
- 10.000 QC Results per Level
- Support
- Online Service Interface
- Sample Size
- Whole Blood, Serum (95 pi)
- Plasma, QCs {95 pi)
- Urine {180 pi)
- Connectivity
- LAN, Wifi, 4 USB ports
- RS232, LIS
- Number of Parameters
- 5 Total 4 (Simultaneously)
- Veterinary Options
- Feline, Canine, Bovine, Equine, Swine, Ovine, Murine or Open
- 28 Sec Analysis
- 512 Tests/Hour
- 40,000 Results Stored
- Touch Screen Display
- Remote User Access
- Online Service Interface
