Meduvent Standard - Emergency and Transport Ventilator
Long distances or transport times? No power or oxygen supply? With a ventilator which maintains ventilation for an average of 8 hours*, even without an external gas supply, you don’t need to worry about the technology. If required, however, the patient can be supplied with additional oxygen at any time via the universally compatible oxygen inlet tube. This allows inspiratory oxygen concentrations of 21 % to 100 % to be achieved - all without the device consuming any itself.
- The integrated alarm system alerts medical staff in critical situations.
- The hygiene filter protects patient, staff and ventilator from contamination.
- An automatic function check means a user is always on the safe side.
- All common standards and guidelines applied to achieve a dedicated emergency response design.
- Efficient in non-invasive ventilation. Manual ventilation with MEDUtrigger replaces bag mask ventilation.
- Universally compatible O2 connection for controlling oxygen concentration to suit requirements
- Loss-free oxygen supply from 21 % O2 to 100 % O2.
Compact, lightweight and ergonomic
- MEDUVENT Standard weighs just 2.1 kg and has a volume of 3.5 l. This makes it one of the smallest, lightest-weight emergency and transport ventilators in its class.
- MEDUVENT Standard is easy to transport and can be reliably charged using the LIFE-BASE portable unit.
Higher performance and efficiency
- Innovative turbine technology
- Works with and without an oxygen supply
- Long operating time: Average 8 hours on one battery charge*
- Short charging time: From 0 % to 95 % charge in just 2.5 hours
- Flexible charging options: Either via 230 V power supply unit / charger or directly from the 12 V on-board power supply
*Assuming typical ventilation settings for an adult patient
Trigger mechanical breaths entirely in line with requirements
In cardiopulmonary resuscitation (CPR) and in anesthesia induction (RSI: Rapid Sequence Induction), mechanical breaths may need to be administered individually or twice in quick succession. Thanks to MEDUtrigger, MEDUVENT Standard makes this possible, quickly, and ergonomically.
Integrated ventilation modes
-
IPPV (Intermittent Positive Pressure Ventilation): Volume control mandatory ventilation
-
CPAP (Continuous Positive Airway Pressure)
-
Manual
Other available modes and functions
- S-IPPV (Synchronized Intermittent Positive Pressure Ventilation): Assisted volume control ventilation with a trigger time slot of 100 % of expiratory time. For volume control ventilation with variable mandatory minute volume. Provides a mandatory mechanical breath for every attempt at spontaneous breathing.
- SIMV (Synchronized Intermittent Mandatory Ventilation): Assisted volume control ventilation with a trigger time slot of 20 % of expiratory time.
- CPAP + PS (Continuous Positive Airway Pressure + Pressure Support) For pressure support if spontaneous breathing is insufficient or exhausted.
- PRVC + PS (Pressure-Regulated Volume-Controlled Ventilation + Pressure Support) Combines the benefits of pressure and volume-controlled ventilation. Pressure support PS can be used for patients who breathe spontaneously from time to time.
