RayBiotech - Model CTLA4 - Epitope Mapping Peptide Array
The Cytotoxic T-Lymphocyte Associated Protein 4 (CTLA4) Epitope Mapping Peptide Array is a semi-quantitative array displaying 177 synthesized peptides representing the full-length CTLA4. It is suitable for antibody epitope mapping and detection of IgG, IgA, IgM, IgE, etc. in serum, plasma, and many other liquid sample types.
Most popular related searches
epitope
culture medium
secondary antibody
vaccine development
antigen antibody
aptamer
vaccination
antigen production
vaccine product
target protein
Assay Format
Species Detected:
- Human
Compatible Sample Types:
- Ascites
- DNA Aptamers
- Hybridoma cell culture medium
- Other fluids
- Plasma
- Purified antibodies
- Purified protein
- Serum
- Method of Detection: Fluorescence Laser Scanner
- Quantitative/Semi-Quantitative: Semi-Quantitative
- Solid Support: Glass Slide
- Antibody Type:Human IgG, mouse IgG, other isotypes (IgA, IgM, IgE, etc.) derived from most animals, upon request.
Product Specifications
Size: 1, 2, or 4 Slide Kit
Protein Information
Accession Number:
- P16410
Gene Symbols:
- CTLA4
Protein Name & Synonyms: CTLA-4 / CD152
Target Species: Human
Synthesized Protein Sequence: 188 amino acids (Lys36-Asn223, without N-terminal signal peptide)
Peptide Information
- Number of Peptides: 177
- Peptide Length:12-mer
- Peptide Offset: 1-mer
- Peptide Purity: HPLC grade, >95% purity
- Array Printing Replicate: Triplicate
- Identify high antigenicity epitopes for antibody production & vaccine development
- Locate (auto)antigen epitopes of (auto)antibodies
- Define the best antibody clone against the protein-of-interest
- Perform epitope mutant analysis
- Map B cell epitopes
- Small serum sample volume required (2 µl)
- High density (simultaneously analyze hundreds of overlapping peptides)
- High sensitivity
- Large dynamic range
- Suitable for high-throughput assays
- High efficiency and accuracy
- Affordable, quick and simple to use
- RayBio® human CLTA-4 protein peptide array
- Blocking Buffer
- Wash Buffer I
- Wash Buffer II
- Biotin-conjugated secondary antibody
- Cy3 equivalent dye conjugated streptavidin
- Array accessories (including slide incubation chamber assembly, gasket, adhesive plastic strips, etc.)
- Distilled water
- Small plastic boxes or containers
- Orbital shaker or oscillating rocker
- Pipettors, pipette tips and other common lab consumables
- Aluminum foil
- Laser fluorescence scanner
View Compatible Laser Scanners
Don`t have a compatible scanner? RayBiotech now offers FREE scanning service for all RayBio glass slide antibody arrays! Learn More
Upon receipt, all kit components should be stored at -20 °C to -80 °C until ready to use. Stored properly, the kit will retain complete activity for up to 6 months.
- This product is furnished for LABORATORY RESEARCH USE ONLY.
- Not for diagnostic or therapeutic use.
