CAD-Ray
Most popular related searches
Image Quality
- Less graininess – Enhanced image
- Contrast resolution – Best at the penny test
- Spatial Resolution – 19-micron pixel size
Patient Comfort
- Ergonomic Design with round corners – 6.0mm radius
- Thin Snesor Plate – 5.4mm (less than 1/4″)
- Low Profile Button – 6.0mm
Designed for Durability
- Thinner Cord – Direct USB from sensor plate to computer
- Sturdier Cord Jacket – Fewer wires enables greater protection
- Protected Against Fluids / Contaminants – Sealed Cord / sensor junction
- Repair option – Cord serviceability
Ergonomic Design
- Broad Range of Acceptable Exposure – Superior electronic gain control
- Sang-Resistant Cord – No interface box or cord bulge
- Easy Cleaning – Immiscible in glutaraldehyde and other disinfectants
Parameter
- IoDS-2401
- IoDS-2402
Dimension (mm)
- 39 x 25
- 42 x 30
Image Size (mm)
- 30 x 20
- 34 x 26
Image Resolution (lp/mm)
- 25 Pixel Size (μm)
- 20 Pixel Pitch (μm)
- 20
Total Pixels (px)
- 1.5M
- 2.2M
Effective Pixels (px)
- 1000 x 1500
- 1300 x 1700
Sensor technology
- CMOS with Optical Fiber
Scintillator
- Csl (Tl)
Interface
- USB 2.0 high speed
Frame rate (fps)
- 1.4
- 1
Cord Length (ft)
- 6.5
