Onda - Model RFB-2000 - Radiation Force Balance
FromOnda Corporation
Designed specifically for easy Ultrasound Power measurements on medical devices, the RFB-2000 requires little maintenance and no complex correction factors, and is compliant with regulatory requirements including AIUM-NEMA UD-2, UD-3, IEC 61161, and with associated IEC standards. Automation assures reliable means to validate Acoustic Output measurements as recommended by AIUM-NEMA document UD-2.
Most popular related searches
medical device
physiotherapy
medical ultrasound device
medical monitoring system
physiotherapy system
medical ultrasound
- Calibrated total acoustic power measurements traceable to national laboratory.
- Easy-to-use software with transparent top-loading configuration
- Insensitive to water level and auto-correction to temperature.
- Wide range of power levels for diagnostic, physiotherapy, and HIFU applications
- Flexible software to support Engineering and Production environments
- Power ranges:
- 1 mW* to 2W with standard absorbing target
- Up to 20W with cone target kit (RFB-CTK)
- Up to 100W† with brush target (RFB-BTK)
- MDisplay Resolution: > 4 digits
- Typical measurement uncertainty*: < ± 5% at 95% confidence level
- Measurement cycle time: adjustable from 4s (default) to 120 s
- Maximum beam diameter: 5 cm
- Low Frequency Limit: 1MHz*
* Usable at lower frequency with decreased accuracy
- RFB-CTK - cone target kit. Includes cone target and absorbing tank liner.
- RFB-BTK - brush target
- RFB-PMP - water-compatible vacuum pump (specify voltage)
- RFB-MSK1X1 - Mask Kit - for Thermal Index (1cm x 1cm window)
