Lenstec - Model SBL-2 - Segmented Bifocal Lens

The Lenstec SBL-2 provides both surgeon and patient a very high level of confidence based on the manufacturing tolerances and the availability of 0.25 Diopter power increments.  This process enables Lenstec to manufacture the SBL-2 to an industry leading ±0.11 Diopters of the intended power, allowing it to be distinguished as part of the Precision Series.    The SBL-2 comes with a true 2.0 diopter sector-shaped add with a seamless transition zone between the distance and near segments.

Several prospective studies have been performed on the SBL-2, with results identifying a high level of near, intermediate and distance vision, very limited amounts of visual side effects and extremely high patient satisfaction and spectacle independence ratings.

• Optic Size:5.75mm
• Optic Type: Bi-Aspheric
• Length: 11.00 mm
• Haptic Style: Modified Plate
• Angulation: 0 Degrees
• Position Holes: 0
• Construction: 1 Piece
• Optic Material: Acrylic (26% water)

• Dual Optic
• +2.0D ADD
• Quarter Diopter Precision
• Enhanced Depth of Vision
• Square Edge Technology
• Micro Incision
• Patented Bi-Aspheric Zero Aberration Optic

A Constant Optimized:

• Immersion: A = 118.00
• SRK/T: A = 118.00
• Holladay-1: sf = 1.22
• Hoffer Q: pACD = 4.97
• Haigis*:
• a0=0.537
• a1=0.333
• a2=0.126

Diopter Range:

• Whole/Half +10.0 to +36.0
• Quarter: +15.0 to 25.0

A Constant and A/C Depth figures shown are strictly guidelines for the calculation of implant power. Lenstec recommends that surgeons develop their own values based on technique, measuring equipment and desired postoperative results.
