RayBio - Model SARS-CoV-2 - Spike Protein Overlapping Peptide Array
The SARS-CoV-2 Spike Protein Overlapping Peptide Array is semi-quantitative array displaying 316 synthesized peptides representing the full-length SARS-CoV-2 Spike protein (wild-type). It is suitable for antibody epitope mapping and detection of IgG, IgM, or IgA in serum, plasma, and other liquid sample types.
Most popular related searches
spike protein
sars-cov-2
slide production
COVID 19
culture medium
secondary antibody
vaccine development
epitope
vaccination
immune response
Species Detected:
- Human
- Mouse
- Rabbit
Compatible Sample Types:
- Ascites
- Hybridoma cell culture medium
- Other fluids
- Plasma
- Purified antibodies
- Purified protein
- Serum
- Method of Detection:Fluorescence Laser Scanner
- Quantitative/Semi-Quantitative: Semi-Quantitative
- Solid Support:Glass Slide
Product Specifications
- Size:1, 2, or 4 Slide Kit
Protein Information
Accession Number:
- P0DTC2
Protein Name & Synonyms:
- Spike protein, S-Protein, Spike glycoprotein
- Target Species: SARS-CoV-2
Targets Detected
Number of Peptides Detected:316 Overlapping Peptides (representing the full-length of SARS-CoV-2 spike protein
- Vaccine Development: Measure IgG, IgM, or IgA antibody responses to immunization or COVID-19 infection
- In Vitro Diagnostics Research: Identify immunodominant epitopes within the SARS-CoV-2 spike protein
- Epitope Profiling: Profile epitope-specific antibody responses against the SARS-CoV-2 spike protein
- Spike Protein Interaction Studies: Determine the interactions between the SARS-CoV-2 spike protein and other molecules, such as proteins, peptides, and small molecules. (Additional reagents and materials not included in the kit may be required.)
- Small sample volume required
- High density
- High sensitivity
- Large dynamic range
- Suitable for high-throughput assays
- RayBio® SARS-CoV-2 spike protein peptide array
- Blocking Buffer
- Wash Buffer I
- Wash Buffer II
- Biotin-conjugated secondary antibody
- Cy3 equivalent dye conjugated streptavidin
- Array accessories (including slide incubation chamber assembly, gasket, adhesive plastic strips, etc.)
- Distilled water
- Small plastic boxes or containers
- Orbital shaker or oscillating rocker
- Pipettors, pipette tips and other common lab consumables
- Aluminum foil
- Laser fluorescence scanner
View Compatible Laser Scanners
Don`t have a compatible scanner? RayBiotech now offers FREE scanning service for all RayBio glass slide antibody arrays! Learn More
Upon receipt, all kit components should be stored at -20 °C to -80 °C until ready to use. Stored properly, the kit will retain complete activity for up to 6 months.
This product is furnished for LABORATORY RESEARCH USE ONLY.
Not for diagnostic or therapeutic use.
