CorpulsModel CPR - Thorax Compression Device of the Latest Generation

SHARE

With the corpuls cpr, we have created a unique thorax compression device. Unique, because it is optimally suited for use in the heart catheter lab thanks to the radiotransparency of the boards. Unique, because it provides unrestricted access to the thorax while performing the reanimation thanks to its single-arm design. Unique, because the corpuls cpr is the only device on the market that is also approved for children from the age of 8.

Most popular related searches
USE IN THE HOSPITAL

The corpuls cpr enables the therapy in the hospital while the reanimation is still in progress:

  • The boards consist of a radioluminescent material to prevent artefacts on the X-ray image
  • The corpuls cpr grants free access to the patient`s thorax at all times
USER-FRIENDLY OPERATION

The clearly structured colour display and the central soft keys support intuitive use:

  • Reanimation modi in conformity with the currently valid ERC/AHA guidelines
  • Adaptation of pressure depth and pressure frequency also possible while the therapy is in progress
USE IN THE EMERGENCY SERVICES

The corpuls cpr ensures fully automatic, fatigue-proof thorax compression:

  • Fast and secure adjustment allows fast switching to thorax compression by machine
  • After each respiration break or after 100 compressions (continuous mode), the corpuls cpr checks the stamp position after each therapy. If the thorax has collapsed due to the previous compressions, the corpuls cpr automatically compensates a possible height difference between the stamp and the thorax.
REUSABLE STAMPS

The stamps of the corpuls cpr can be easily disinfected and therefore used repeatedly. In addition, the stamps are available in two sizes.

CARRIER BAG/BACKPACK

Always at hand: The custom-tailored PAX® bag. Besides the corpuls cpr arm, it also contains all accessories, such as the board, spare battery, stamp and mains adapter immediately ready for use.

GENERAL SPECIFICATIONS
  • 2.4`` LED colour display, illuminated
  • Well-designed audio-visual alarm system
  • Saving of incident data on the SD card
  • Bluetooth (for data exchange with corpuls3)
  • NFC (for fast pairing)
  • RTCA DO 160 G (selected sections)
  • Operating volume: approx. 70 dB
  • Dust and water spray protected (IP54)
  • Power supply: 12–33 V DC (on-board voltage), 100–240 V AC (mains voltage 50–60 Hz)
CORPULS CPR (ARM WITH STAMP AND BATTERY):
  • Weight : 5.5 kg
  • Operating temperatures : -20 °C to +45 °C
  • Dimensions : 43 cm (H) × 45 cm (W) × 9 cm (D)
PRESSURE PARAMETERS
  • Pressure frequency: 80 to 120 compressions/min (individually adjustable in increments of 1 compression/min)
  • Pressure depth: 2 to 6 cm (individually adjustable in increments of 0.1 cm)
  • Therapy mode: 30:2 / 15:2 / continuous
PATIENT PARAMETERS
  • Thorax height: 14 to 34 cm
  • No restrictions regarding the patient`s weight and breadth of thorax.
OPERATING PARAMETERS
  • Power unit: electric
  • Lithium-polymer (LiPo) battery
  • Battery runtime: 90 min (typical)
  • Display of the remaining runtime in minutes
  • LED display of the charge state in 20% increments on the battery
  • Battery charging time via magnetic plug (no therapy): approx. 105 min 0–80% approx. 30 min 80-100%
  • Intuitive user interface: Therapy start/stop button with alarm function and 4 soft keys
  • Simultaneous display of operating mode, pressure depth, pressure frequency, time/therapy time/remaining battery time in minutes/percent
  • Battery service life: at most 300 load cycles
